General

Reset
Division: Architectural
Architectural products



Physical

Length (mm): 84
Length (in): 3 1⁄3
Width (mm): 40
Width (in): 1 9⁄16
Height (mm): 25
Height (in): 1
Weight (kg): 0.154
Weight (lbs): 0.339
Fixture Material: Plastic



Electrical

Lamp Type: LED
Total Output Wattage (W): 16.8-29.4
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V Dimming)
Driver Type: Constant Current - Universal
Driver Class: Class 2
Input Voltage (V): 120 - 277
Constant Current (MA): 700
Constant Voltage (V): 24-42
Upon Request: 0-10Vdc dimming / Phase dimming @120Vac only / 277Vac



LED



Optical



Ratings and Certifications

Certified By: UR Listed
Code Compliance: Title 24 commercial Installation
IP rating: Dry / Damp





Base Model Number: DTM0290700ES

Description

ERP - ESS030W-0700-42 - 0-10Vdc & Phase [Leading and Trailing Edge @120Vac only] dimming - 29.4W - 700mA - 120 / 277Vac - LED power supply -Used with ENCP3 -Available with IP68-Outdoor Rated -ENCP20, ENCP22
