Mini Corniche – Zaneen
Surface
Mini Corniche - Surface

Features Inspiration Video

General

Reset
Series: Mini Corniche
Partner: Platek
Platek products
Division: Exterior
Exterior products
Installation: Surface
Surface products
Product Type: Wall Grazer, Wallwash
Mounting Location: Wall
Wall products
Light Distribution: Adjustable
Adjustable products



Physical

Shape: Rectangle
Length (mm): 600, 900
Length (in): 23 5⁄8, 35 7⁄16
Width (mm): 32
Width (in): 1 1⁄4
Height (mm): 32
Height (in): 1 1⁄4
Extension (mm): 55
Extension (in): 2 3⁄16
Weight (kg): 1.8, 2.2
Weight (lbs): 4.0, 4.8
Screws: A4 stainless steel
Gasket: Gore-Tex valve to prevent condensation inside the fitting.
Fixture Material: Extruded Aluminum



Electrical

Lamp Type: LED
Input Wattage (W): 18.5 / 10.5 (Dif), 29 / 15.5 (Dif)
Total Output Wattage (W): 18 / 10 (Dif), 27 / 15 (Dif)
Driver Included: No
Driver Location: Remote
Driver Type: Constant Voltage - 120 / 277Vac
Driver Class: Class 2
Input Voltage (V): 120 - 277
Output Voltage (V): 24
Upon Request: (Not included - see components [IP65 or higher enclosure to be supplied by others]) 0-10Vdc dimming / Phase dimming / Non-dimming 120/277Vac



LED

Number of LEDs: 18, 27
Color Temperature (°K): 3000
Max. Delivered Lumen (lm): 1500, 2260
Nominal Lumen (lm): 2520, 3780
CRI: >80 CRI
Lamp Life (hrs): 60000



Optical

Optic°: 13, 40°



Ratings and Certifications

Certified By: Certified for North American Standards
IP rating: IP65
IK Rating: IK06
Bug Rating: B2 U1 G0, B3 U1 G1
Upon Request: Higher Maximum Ambient Temperature





Mini Corniche 2 matching products

Mini Corniche by Platek – 23 5/8″ x 1 1/4″ Surface, Wallwash offers high performance and quality material | Zaneen Exterior E9W536- : E9W536-30K-GRY-40 Mini Corniche - 600mm / 23 5/8" - Surface - Wall Effect - 18.5W (18 LED) - 3000K - 1400lm - Optics: 40° - Gray
Quick Ship
Mini Corniche by Platek – 35 7/16″ x 1 1/4″ Surface, Wall Grazer offers high performance and quality material | Zaneen Exterior E9W554- : E9W554-30K-BRZ-13 Mini Corniche - 900 / 35 7/16" - Surface - Wall Effect - 29W (27 LED) - 3000K - 2260lm - Optics: 13° - Bronze
Quick Ship

Key Features:
  • Precise wall illumination with configurable optics - 13°, 26°, 40°, elliptical (ELL), or diffused (DIF) - gives greater control and texture highlighting.
  • Installation flexibility with surface and recess mount options.

Series Description

Mini Corniche is a family of exterior linear profile lights that consists of walkover, downlight, and surface mount and available in lengths ranging in size, each available in five beam spreads. Constructed of corrosion resistant, die-cast aluminum alloy, Mini Corniche is protected with anodizing treatment, epoxy powder base coating and polyester painting in a variety of color finish options. An ingress protection of IP66 and impact resistance of IK10; a gore valve prevents condensation inside the fixture.

Manufactured in Italy, by Platek.
