Series: Mini One 2.0

Partner: Platek

Division: Exterior

Installation: Surface

Product Type: Wall Surface

Mounting Location: Wall

Light Distribution: Direct

Physical

Shape: Cube

Width (mm): 100

Width (in): 3 ¹⁵⁄₁₆

Height (mm): 100

Depth (mm): 100

Height (in): 3 ¹⁵⁄₁₆

Depth (in): 3 ¹⁵⁄₁₆

Weight (kg): 1.1

Weight (lbs): 2.43

Screws: No visible screws

Diffuser: Serigraphed extra-clear glass

Fixture Finish: BLK / WHI / GRY / COR / ANT / BRZ

see color chart below

Fixture Material: Aluminum Die Cast

Electrical

Lamp Type: LED

Input Wattage (W): 3, 4, 7.6

Dimming: Non-Dimmable

Driver Included: Yes

Driver Location: Integrated

Driver Type: Constant Current - Universal

Driver Class: Class 2

Input Voltage (V): 120 - 277

Constant Current (MA): 350

LED

Number of LEDs: 1, 2, 4

Color Temperature (°K): 2700 / 3000 / 4000

Max. Delivered Lumen (lm): 25, 50, 100, 198, 396

CRI: >90 CRI

Lamp Life (hrs): 60000

Optical

Optic°: 1 Opening, 2 Opening, 4 Lenses, 90

Beam Angle: 2 Lenses, Diffused

Ratings and Certifications

Certified By: Certified for North American Standards

IP rating: IP65

IK Rating: IK07

Upon Request: Higher Maximum Ambient Temperature

Mini One 2.0 5 matching products

	E9W619-	Mini One 2.0 - Surface - Wall Effect - 1 Lens - 1 x 3W LED - 2700K / 3000K / 4000K - Max 25lm
	E9W620-	Mini One 2.0 - Surface - Wall Effect - 2 Lens - 4W LED - 2700K / 3000K / 4000K - Max 50lm
	E9W621-	Mini One 2.0 - Surface - Wall Effect - 4 Lens - 7.6W LED - 2700K / 3000K / 4000K - Max 100lm
	E9W623-	Mini One 2.0 - Surface - Wall Effect - 4W LED - 2700K / 3000K / 4000K - Max 198lm - 90°
	E9W624-	Mini One 2.0 - Surface - Wall Effect - 2 Opening - 7.6W LED - 2700K / 3000K / 4000K - Max 396lm

Series Description

Mini One 2.0 is a compact and stylish exterior lighting solution designed for versatility and elegance. Its geometric cube design is complemented by its functional features, making it perfect for various lighting applications. With its sleek and seamless appearance, Mini One 2.0 enhances any space without the distraction of visible screws or wall mounts. Choose between the two-window or four-window options or opt for the blade of light version for a unique lighting effect. The product undergoes a galvanic anodizing treatment, consisting of mechanical satin finishing, surface degreasing, anodic oxidation, and final sealing. This multi-step process guarantees a protective coating that shields the fixture from atmospheric agents and UV rays.

Manufactured in Italy, by Platek.
