Airliner Surface Wall, 280mm/11", 9W LED, 2700K / 3000K, 85lm, CRI90, Non-Dimming / 0-10V Dimming – Zaneen

General

Series: Airliner

Partner: Platek
Platek products

Division: Exterior
Exterior products

Installation: Surface
Surface products

Product Type: Wall Surface
Wall Surface products

Mounting Location: Wall
Wall products

Light Distribution: Direct
Direct products



Physical

Shape: Cylinder

Width (mm): 83

Width (in): 3 14

Depth (mm): 225

Depth (in): 8 78

Max. Overall Height (mm): 280

Max. Overall Height (in): 11

Screws: No visible screws

Diffuser: Transparent extra Clear Glass

Fixture Finish: BLK / ANT
see color chart below

Fixture Material: Aluminum Die Cast

Upon Request: Finishes - Black



Electrical

Lamp Type: LED

Input Wattage (W): 10.5

Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V Dimming)

Driver Included: Yes

Driver Location: Integrated

Driver Type: Constant Current - Universal

Driver Class: Class 2

Input Voltage (V): 120 - 277

Constant Current (MA): 700



LED

Color Temperature (°K): 2700 / 3000

Max. Delivered Lumen (lm): 85

Nominal Lumen (lm): 690

CRI: >90 CRI

Lamp Life (hrs): 50000



Optical



Ratings and Certifications

Certified By: Certified for North American Standards

IP rating: IP65

IK Rating: IK06





Base Model Number: E9W651-

Description

Airliner is a series of surface, suspension and bollard fixtures that transform outdoor spaces with its striking interplay of light and form. The innovative fixture leaves a mark on the landscape thanks to the linear slits along the fixture's body, which create a dynamic and ever-changing projection on its surroundings. By infusing exterior environments with movement of light, Airliner brings a unique energy and vibrancy to any setting.

Manufactured in Italy, by Platek.

Also Available within Series

Airliner by Platek – 3 1/8″ x 47 1/4″ Post, Bollard - Garden offers high performance and quality material | Zaneen Exterior E9B308- Airliner Bollard, 1200mm/47 1/4", 9W LED, 2700K / 3000K, 85lm, CRI90, Non-dimming
Airliner by Platek – 3 1/8″ x 10 1/4″ Suspension, Pendant offers high performance and quality material | Zaneen Exterior E9S010- Airliner Suspension, 260mm/10 1/4", 6.1W LED, 2700K / 3000K, 70lm, CRI90, Non-Dimming
Airliner by Platek –  Surface, Wall Surface offers high performance and quality material | Zaneen Exterior E9W651- Airliner Surface Wall, 280mm/11", 9W LED, 2700K / 3000K, 85lm, CRI90, Non-Dimming / 0-10V Dimming

Downloads

Airliner by Platek –  Surface, Wall Surface offers high performance and quality material | Zaneen Exterior

Airliner by Platek –  Surface, Wall Surface offers high performance and quality material | Zaneen Exterior

Wall
Direct
Included or excluded LED driver/transformer/ control gear
Dimmable
Color rendering index

>90 CRI
Color temperature

2700 / 3000
Lumen (luminous flux)

85
Certified for North American Standards
Protected against ingress of dust; protected against jets of water
Protected against 1 joules impact (equivalent to 0.25kg mass dropped from 400mm above the surface)


Fixture Finishes

BLK - Black ANT - Anthracite
Note: the color samples are digitally reproduced and may not accurately depict the actual colors.
