Suspension

Finishes Inspiration

General

Reset

Series: Victory Acoustic Light Panel

Partner: Prolicht

Division: Architectural

Installation: Suspension

Product Type: Acoustic

Mounting Location: Ceiling

Light Distribution: Indirect

Physical

Shape: Abstract

Length (mm): 496, 792, 1092

Length (in): 19 ¹⁄₂, 31 ³⁄₁₆, 43

Width (mm): 448, 704, 964

Width (in): 17 ⁵⁄₈, 27 ¹¹⁄₁₆, 37 ¹⁵⁄₁₆

Height (mm): 54

Height (in): 2 ¹⁄₈

Fixture Finish: SSR / BKV / CWI / CRY / HAB / UFT / ITA / RUA / FTG / MYG / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG / MEY / GOH / CHC / COM / ABZ / JAG / OBR / MOS / ROR

see color chart below

Acoustic Finish: SFW / CYW / SEE / SYN / MTS / PMB / TTN / CYB / STO / DPE / BES / SHB / ARE / ANE / VRD / CRF

Fixture Material: Aluminum

Primary Material: Acoustic

Cable Details: 2000mm / 78 3/4" or 6000mm / 236 1/4" Transparent Cable

Electrical

Lamp Type: LED (Zhaga Standard)

Input Wattage (W): 10, 23.8

Total Output Wattage (W): 9.1, 21.8

Dimming: Non-Dimmable

Driver Included: Yes

Driver Location: Integrated

Driver Type: Constant Current - Universal

Driver Class: Class 2

Input Voltage (V): 120 - 277

LED

Color Temperature (°K): 2700 / 3000 / 3500 / 4000

Max. Delivered Lumen (lm): 701 / 708 / 730 / 751, 1753 / 1771 / 1824 / 1877

Nominal Lumen (lm): 855 / 864 / 890 / 916, 1753 / 2225 / 2160 / 2290

CRI: >90 CRI

Lamp Life (hrs): 50000

Optical

Ratings and Certifications

Certified By: CSA Certified to UL and CSA Standards

IP rating: IP20

Victory Acoustic Light Panel 3 matching products

	A300747-	Victory Acoustic Light Panel - Suspension 496mm/19 1/2" x 448mm/17 5/8" with Acoustic Panel - Indirect - 9.5W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 751lm - CRI90 - Dimmable
	A300748-	Victory Acoustic Light Panel - Suspension - 792mm/31 3/16" x 704mm/27 11/16" with Acoustic Panel - Indirect - 9.5W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 751lm - CRI90 - Dimmable
	A300749-	Victory Acoustic Light Panel - Suspension - 1092mm/43" x 964mm/37 15/16" with Acoustic Panel - Indirect - 23.8W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 1877lm - CRI90 - Dimmable

Series Description

Victory Acoustic Light Panel is a complement to the Victory Acoustic luminaires, we now offer Light Panels in the same popular triangular geometric shape. These panels provide indirect lighting, resulting in a seamless ceiling appearance. They open up new possibilities for lighting design while enhancing room acoustics. Choose from a curated and extensive selection of refined colors, ensuring seamless customization to complement any interior design.

Manufactured in Austria, by Prolicht.
