Hangover Plug - Track Head - 28mm / 1 1/8" x 450mm / 17 11/16" - 6.4W LED (Zhaga Standard) - 2700K / 3000K / 4000K - Lens 24°/32°/58° - Shine Ring – Zaneen

General

Series: Clicktrack

Subseries: Hangover Plug Standard (Track Insert)

Partner: Prolicht
Prolicht products

Division: Architectural
Architectural products

Installation: Track
Track products

Product Type: Pendant
Pendant products

Mounting Location: Ceiling
Ceiling products

Light Distribution: Downlight
Downlight products



Physical

Shape: Cylinder

Diameter (mm): 28

Diameter (in): 1 18

Height (mm): 450

Height (in): 17 1116

Max. Overall Height (mm): 2450

Max. Overall Height (in): 96 716

Weight (kg): 0.32

Weight (lbs): 0.706

Diffuser: Shine Ring 1-6

Fixture Finish: SSR / BKV / CWI / CRY / HAB / UFT / ITA / RUA / FTG / MYG / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG / MEY / GOH / CHC / COM / ABZ / JAG / OBR / MOS / ROR
see color chart below

Fixture Material: Aluminum

Cable Details: 2000mm or 4000mm Cable - Black



Electrical

Lamp Type: LED (Zhaga Standard)

Input Wattage (W): 6.4

Total Output Wattage (W): 5.8

Dimming: Non-Dimmable

Driver Included: No

Driver Location: Remote

Driver Type: Constant Voltage - Universal

Driver Class: Class 2

Input Voltage (V): 120

Constant Current (MA): 500

Upon Request: 0-10Vdc dimming / DALI dimming



LED

Number of LEDs: 1

Color Temperature (°K): 2700 / 3000 / 4000

Max. Delivered Lumen (lm): 328 / 363 / 386

CRI: >90 CRI

Upon Request: ***3500K available in minimum quantities (larger quantities upon request)



Optical

Optic°: 24 / 32 / 58



Ratings and Certifications

Certified By: Certified for North American Standards

IP rating: IP20





Base Model Number: A3T122-

Description

ClickTrack is a track system where spots are mounted simply by clicking them into the track, without the need for tools. The cable of the pendulum variants can be flexibly shortened or extended at any time. The great flexibility of the ClickTrack extension system ensures perfectly coordinated lighting concepts, for living areas, in retail, for hotels or in public buildings. Select from 25+ standard colors, ensuring limitless customization to complement any interior design.

Manufactured in Austria, by Prolicht.

This component relates to

Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK25-TRI-SYS Clicktrack 25 Modular System - Trimless
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK30-SUR-SYS Clicktrack 30 Modular System - Surface Ceiling
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK30-SUS-SYS Clicktrack 30 Modular System - Suspension
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK50-TRI-SYS Clicktrack 50 Modular System - Trimless

Also Available within Series

Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK25-TRI-SYS Clicktrack 25 Modular System - Trimless
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK30-SUR-SYS Clicktrack 30 Modular System - Surface Ceiling
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK30-SUS-SYS Clicktrack 30 Modular System - Suspension
Clicktrack by Prolicht –  Track, Track System Low Voltage offers LED lighting solutions | Zaneen Architectural A3CLK50-TRI-SYS Clicktrack 50 Modular System - Trimless

Downloads

Clicktrack by Prolicht – 1 1/8″ x 17 11/16″ Track, Pendant offers LED lighting solutions | Zaneen Architectural

Clicktrack by Prolicht – 1 1/8″ x 17 11/16″ Track, Pendant offers LED lighting solutions | Zaneen Architectural

Ceiling
Lens

24 / 32 / 58
Integrated shine ring with diffuser
Free individual colors 01-29
Color rendering index

>90 CRI
Color temperature

2700 / 3000 / 4000
Lumen (luminous flux)

328 / 363 / 386
Certified for North American Standards
Protected against ingress of solid bodies greater than 12.5mm (finger)


Fixture Finishes

SSR - Sparkling Silver BKV - Black Velvet CWI - Crystal White CRY - Creamy HAB - Hampton Bay UFT - Urban Forest ITA - In the Army RUA - Rusty Angel FTG - Fade to Gray MYG - Mysterious Gray LOD - Lost Dream PUS - Purple Sky FRO - Fresh Oh FUP - Funky P. KIA - Kissing Aphrodite POP - Poseidon's Paradise BLS - Blue Sky SPG - Spring Green MEY - Mellow Yellow GOH - Golden Heart CHC - Champagne Cream COM - Copper Mine ABZ - Ancient Bronze JAG - Jazz Gold OBR - Olive Breeze	MOS - Moonlight Silver ROR - Rosewood Red
Note: the color samples are digitally reproduced and may not accurately depict the actual colors.
