Infinite Honeycomb, Surface Ceiling Panel, 1508mm/59 3/8" x 1306mm/51 7/16", 90W LED, 2700K / 3000K / 3500K / 4000K, Max 5962lm, 24V, CRI:93, IP20 - – Zaneen

General

Reset
Series: Infinite Honeycomb
Partner: Ivela
Ivela products
Division: Architectural
Architectural products
Installation: Surface
Surface products
Product Type: Panels
Panels products
Mounting Location: Ceiling
Ceiling products
Light Distribution: Direct
Direct products



Physical

Shape: Hexagon
Length (mm): 1508
Length (in): 59 3⁄8
Width (mm): 1306
Width (in): 51 7⁄16
Height (mm): 19
Height (in): 1 1⁄16
Diffuser: PMMA - Opal
Fixture Finish: WHI / BLK / GLD
see color chart below
Fixture Material: Aluminum



Electrical

Lamp Type: LED
Input Wattage (W): 90
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V Dimming)
Driver Included: No
Driver Location: Remote
Driver Type: Constant Voltage - Universal
Driver Class: Class 2
Housing: ENCP 8 (SC Power) ENCP 10 (Mean Well)
Input Voltage (V): 120 - 277
Output Voltage (V): 24



LED

Color Temperature (°K): 2700 / 3000 / 3500 / 4000
Max. Delivered Lumen (lm): 5400 / 5625 / 5792 / 5962
Nominal Lumen (lm): 10800 / 11250 / 11585 / 11925
CRI: >93 CRI
Lamp Life (hrs): 50000



Optical



Ratings and Certifications

Certified By: CSA Certified to UL and CSA Standards
IP rating: IP20





Base Model Number: A56196-

Specify

Description

Infinite Honeycomb is a series of trimless LED panels that redefine ceiling lighting with a modern and versatile design tailored for the most demanding environments. Perfect for expansive spaces and professional settings, Infinite Honeycomb ensures exceptional light quality, enhancing both functionality and atmosphere. Featuring a striking hexagonal shape with an open inner portion, Infinite Honeycomb combines architectural elegance with practical lighting solutions. Available as surface-mounted or suspended panels, it seamlessly adapts to various applications while making a bold design statement. Choose from a selection of refined color finishes to complement any aesthetic. Infinite Honeycomb is the ideal blend of form and function, elevating contemporary interiors with its innovative design.

Manufactured in Italy, by Ivela.

Product Components to be ordered separately

Image SKU Description Datasheet
DVO1200024MB MeanWell - HLG-120H-24B - 1-10Vdc / Resistance / 10V PWM Dimming - 120W - 24Vdc - 120-277Vac - LED power supply
ENCP8 Empty Metal Enclosure for Driver - IP20 - Indoor Rated

Also Available within Series

Infinite Honeycomb by Ivela – 43 11/16″ x 1 1/16″ Suspension, Panels offers LED lighting solutions | Zaneen Architectural A51094- Infinite Honeycomb, Suspension Panel, 1008mm/39 11/16" x 873mm/34 3/8", 60W LED, 2700K / 3000K / 3500K / 4000K, Max 3975lm, 24V, CRI:93, IP20 -
Infinite Honeycomb by Ivela – 59 3/8″ x 1 1/16″ Suspension, Panels offers LED lighting solutions | Zaneen Architectural A51095- Infinite Honeycomb, Suspension Panel, 1508mm/59 3/8" x 1306mm/51 7/16", 90W LED, 2700K / 3000K / 3500K / 4000K, Max 5962lm, 24V, CRI:93, IP20 -
Infinite Honeycomb by Ivela – 79 1/16″ x 1 1/16″ Suspension, Panels offers LED lighting solutions | Zaneen Architectural A51096- Infinite Honeycomb, Suspension Panel, 2008mm/79 1/16" x 1739mm/68 7/16", 120W LED, 2700K / 3000K / 3500K / 4000K, Max 7950lm, 24V, CRI:93, IP20 -
Infinite Honeycomb by Ivela – 43 11/16″ x 1 1/16″ Surface, Panels offers LED lighting solutions | Zaneen Architectural A56195- Infinite Honeycomb, Surface Ceiling Panel, 1008mm/39 11/16" x 873mm/34 3/8", 60W LED, 2700K / 3000K / 3500K / 4000K, Max 3975lm, 24V, CRI:93, IP20 -
Infinite Honeycomb by Ivela – 59 3/8″ x 1 1/16″ Surface, Panels offers LED lighting solutions | Zaneen Architectural A56196- Infinite Honeycomb, Surface Ceiling Panel, 1508mm/59 3/8" x 1306mm/51 7/16", 90W LED, 2700K / 3000K / 3500K / 4000K, Max 5962lm, 24V, CRI:93, IP20 -
Infinite Honeycomb by Ivela – 79 1/16″ x 1 1/16″ Surface, Panels offers LED lighting solutions | Zaneen Architectural A56197- Infinite Honeycomb, Surface Ceiling Panel, 2008mm/79 1/16" x 1739mm/68 7/16", 120W LED, 2700K / 3000K / 3500K / 4000K, Max 7950lm, 24V, CRI:93, IP20 -

Downloads

Request Files

Infinite Honeycomb by Ivela – 59 3/8″ x 1 1/16″ Surface, Panels offers LED lighting solutions | Zaneen Architectural

Infinite Honeycomb by Ivela – 59 3/8″ x 1 1/16″ Surface, Panels offers LED lighting solutions | Zaneen Architectural

Ceiling
Direct
Dimmable
Color rendering index

>93 CRI
Color temperature

2700 / 3000 / 3500 / 4000
Lumen (luminous flux)

5400 / 5625 / 5792 / 5962
CSA Certified to UL and CSA Standards
Protected against ingress of solid bodies greater than 12.5mm (finger)


Fixture Finishes

WHI - White BLK - Black GLD - Gold
Note: the color samples are digitally reproduced and may not accurately depict the actual colors.
