Quantum Acoustic -Suspension 800mm/31 1/2" x 800mm/31 1/2" with Acoustic Panel - Direct/Indirect - 58.7W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 6423lm - CRI90 - Diffuser - Dimmable – Zaneen

General

Reset
Series: Quantum Acoustic
Partner: Prolicht
Prolicht products
Division: Architectural
Architectural products
Installation: Suspension
Suspension products
Product Type: Acoustic
Acoustic products
Mounting Location: Ceiling
Ceiling products
Light Distribution: Direct
Direct products



Physical

Shape: Round
Length (mm): 800
Length (in): 31 1⁄2
Width (mm): 800
Width (in): 31 1⁄2
Height (mm): 120
Height (in): 4 3⁄4
Diffuser: PMMA - Opal / Micro-Prism
Fixture Finish: SSR / BKV / CWI / CRY / HAB / UFT / ITA / RUA / FTG / MYG / LOD / PUS / FRO / FUP / KIA / POP / BLS / SPG / MEY / GOH / CHC / COM / ABZ / JAG / OBR / MOS / ROR
see color chart below
Acoustic Finish: SFW / CYW / SEE / SYN / MTS / PMB / TTN / CYB / STO / DPE / BES / SHB / ARE / ANE / VRD / CRF
Fixture Material: Aluminum
Primary Material: Acoustic
Cable Details: 2000mm / 78 3/4" or 6000mm / 236 1/4" Transparent Cable



Electrical

Lamp Type: LED (Zhaga Standard)
Input Wattage (W): 58.7
Total Output Wattage (W): 53.7
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V Dimming)
Driver Included: Yes
Driver Location: Integrated
Driver Class: Class 2
Input Voltage (V): 120



LED

Color Temperature (°K): 2700 / 3000 / 3500 / 4000
Max. Delivered Lumen (lm): Max 6423
Nominal Lumen (lm): Max 8759
CRI: >90 CRI
Lamp Life (hrs): 50000



Optical



Ratings and Certifications

Certified By: CSA Certified to UL and CSA Standards
IP rating: IP20





Base Model Number: A300735-

Specify

Description

Quantum Acoustic is an expansion of the popular Quantum collection which has been innovatively enhanced with acoustic materials. The previously hollow interior of the quadrilateral luminaires are now fitted with an acoustic panel, creating a design feature that not only adds visual appeal but also improves sound quality in any space. The acoustic panel material adds another element to this fixture, creating an alliance between function and design. Choose from a curated and extensive selection of refined colors, ensuring seamless customization to complement any interior design.

Manufactured in Austria by Prolicht.

Also Available within Series

Quantum Acoustic by Prolicht – 31 1/2″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300732- Quantum Acoustic -Suspension 800mm/31 1/2" x 800mm/31 1/2" with Acoustic Panel - Direct - 29.4W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 4034lm - CRI90 - Diffuser - Dimmable
Quantum Acoustic by Prolicht – 43 5/16″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300733- Quantum Acoustic -Suspension 1100mm/43 5/16" x 1100mm/43 5/16" with Acoustic Panel - Direct - 58.7W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 6051lm - CRI90 - Diffuser - Dimmable
Quantum Acoustic by Prolicht – 55 1/8″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300734- Quantum Acoustic -Suspension 1400mm/55 1/8" x 1400mm/55 1/8" with Acoustic Panel - Direct - 78.3W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 8068lm - CRI90 - Diffuser - Dimmable
Quantum Acoustic by Prolicht – 31 1/2″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300735- Quantum Acoustic -Suspension 800mm/31 1/2" x 800mm/31 1/2" with Acoustic Panel - Direct/Indirect - 58.7W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 6423lm - CRI90 - Diffuser - Dimmable
Quantum Acoustic by Prolicht – 43 5/16″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300736- Quantum Acoustic -Suspension 1100mm/43 5/16" x 1100mm/43 5/16" with Acoustic Panel - Direct/Indirect - 97.9W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 9591lm - CRI90 - Diffuser - Dimmable
Quantum Acoustic by Prolicht – 55 1/8″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural A300737- Quantum Acoustic -Suspension 1400mm/55 1/8" x 1400mm/55 1/8" with Acoustic Panel - Direct / Indirect - 117.5W LED (Zhaga Standard) - 2700K / 3000K / 3500K / 4000K - Max. 11338lm - CRI90 - Diffuser - Dimmable

Downloads

Request Files

Quantum Acoustic by Prolicht – 31 1/2″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural

Quantum Acoustic by Prolicht – 31 1/2″ x 4 3/4″ Suspension, Acoustic offers LED lighting solutions | Zaneen Architectural

Ceiling
Direct
Included or excluded LED driver/transformer/ control gear
Length of suspension cable
Free individual colors 01-29
Dimmable
Color rendering index

>90 CRI
Color temperature

2700 / 3000 / 3500 / 4000
Lumen (luminous flux)

Max 6423
Acoustic material
CSA Certified to UL and CSA Standards
Protected against ingress of solid bodies greater than 12.5mm (finger)


Fixture Finishes

SSR - Sparkling Silver BKV - Black Velvet CWI - Crystal White CRY - Creamy HAB - Hampton Bay UFT - Urban Forest ITA - In the Army RUA - Rusty Angel FTG - Fade to Gray MYG - Mysterious Gray LOD - Lost Dream PUS - Purple Sky FRO - Fresh Oh FUP - Funky P. KIA - Kissing Aphrodite POP - Poseidon's Paradise BLS - Blue Sky SPG - Spring Green MEY - Mellow Yellow GOH - Golden Heart CHC - Champagne Cream COM - Copper Mine ABZ - Ancient Bronze JAG - Jazz Gold OBR - Olive Breeze MOS - Moonlight Silver ROR - Rosewood Red

Acoustic Finishes

SFW - Snowfall White CYW - Creamy White SEE - Stone Echo SYN - Smoky Iron MTS - Midnight Stone PMB - Phantom Black TTN - Twilight Navy CYB - Cloudy Blue STO - Soft Olive DPE - Deep Evergreen BES - Bronze Shadow SHB - Savannah Brown ARE - Amber Earth ANE - Autumn Ember VRD - Vintage Red CRF - Coral Reef
Note: the color samples are digitally reproduced and may not accurately depict the actual colors.
