RA16 - Dixit - Recessed - 18W LED - 2700K/3000K/3500K/4000K - CRI 85 - IP44 - Matte White - Optic 110° – Zaneen

General

Reset
Series: Dixit
Subseries: Dixit RA16
Partner: Ivela
Ivela products
Division: Architectural
Architectural products
Installation: Recessed
Recessed products
Product Type: Downlight
Downlight products
Mounting Location: Ceiling
Ceiling products
Light Distribution: Direct
Direct products



Physical

Shape: Round
Diameter (mm): 160
Diameter (in): 6 5⁄16
Height (mm): 42
Height (in): 1 5⁄8
Min. Recessing Depth (mm): 82
Min. Recessing Depth (in): 3 1⁄4
Weight (kg): 0.7
Weight (lbs): 15.43
Diffuser: Polycarbonate - Opal
Fixture Finish: MWH
see color chart below
Fixture Material: Aluminum Die Cast
Cut-out Measurements: 155mm / 6 1/8"



Electrical

Lamp Type: LED
Total Output Wattage (W): 18
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V Dimming)
Driver Included: No
Driver Location: Recessed Housing
Driver Type: Constant Current - Universal
Driver Class: Class 2
Input Voltage (V): 120 - 277
Constant Current (MA): 500



LED

Number of LEDs: 1
Color Temperature (°K): 2700 / 3000 / 3500 / 4000
Max. Delivered Lumen (lm): 1745 / 1781
CRI: >85 CRI
Efficiency (%): 72.7
Lamp Life (hrs): 50000



Optical

Optic°: 110
Beam Angle: Symmetric
Adjustability: Fixed



Ratings and Certifications

Certified By: Certified for North American Standards
IP rating: IP44
IK Rating: IK07





Base Model Number: A56102-

Specify

Description

Dixit is a wide family of recessed specification-grade downlights that are equipped with varying lumen packages, sizes, optics and IP ratings. The family includes multiple subseries, where the names of the series reflect the diameter in cm. With the wide range of technical options available, these downlights can be a single resource for all ceiling heights and applications. Dixit has a solution for all sectors including residential, retail, hospitality, commercial and public spaces. Custom lumen packages, optics and accessories are possible to ensure that the Dixit is the perfect solution for your project. Pick and choose from the multiple subseries within the collection for perfect illumination.

Manufactured in Italy, by Ivela.

Product Components to be ordered separately

Image SKU Description Datasheet
by – , offers LED lighting solutions | Zaneen Architectural CP-155-21-42 Chicago Plenum New Construction Recessed Frame Kit (155mm (6 1/8")), Max. 21W 500mA, Tri-Mode Dimming
by – , offers LED lighting solutions | Zaneen Architectural IC-155-21-42 Insulated Ceiling New Construction Recessed Frame Kit (155mm (6 1/8")), Max. 21W 500mA, Tri-Mode Dimming
by Prolicht – , offers LED lighting solutions | Zaneen Architectural NC-155-21-42 New Construction Recessed Frame Kit (155mm (6 1/8")), Max. 21W 500mA, Tri-Mode Dimming
by – 6 7/64″ x 1 3/8″ , offers LED lighting solutions | Zaneen Architectural RM-21-42 Remodel Housing Kit, Max. 21W 500mA, Tri-Mode Dimming

Also Available within Series

Dixit by Ivela – 3 3/4″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A5601121- RA8 DIXIT LED - Recessed - Adjustable - 12W - 2700K / 3000K / 4000K - 26° - White
Dixit by Ivela – 4 5/16″ x 2 4/4″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56020- RA11 DIXIT LED - Recessed - 12W / 18W / 26W LED - 2700K / 3000K / 4000K - 55° - CRI 85 - Matte White
Dixit by Ivela – 4 15/16″ x 3 1/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56024- RA11 DIXIT LED - Recessed - 12W / 18W / 26W LED - 2700K / 3000K / 4000K - 55° - CRI 85 - Matte White
Dixit by Ivela – 4 15/16″ x 4 1/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56028- RA11 DIXIT LED - Recessed - 12W / 18W / 26W LED - 2700K / 3000K / 4000K - 55° - CRI 85 - Matte White
Dixit by Ivela – 5 9/16″ x 4 5/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56032- RA11 SOFT DIXIT LED - Recessed - 12W / 18W / 26W LED - 2700K / 3000K - 55° - CRI 85 - Matte White
Dixit by Ivela – 3 1/8″ x 2 3/4″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56057- RA8 Q DIXIT LED - Recessed - 9W / 12W LED - 2700K / 3000K CRI 80 - 26° - Matte White
Dixit by Ivela – 3 1/8″ x 2 15/16″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56069- RA8 DIXIT LED - Recessed - 9W / 12W LED - 2700K / 3000K / 4000K - CRI 80 - Optic 26° - Matte White
Dixit by Ivela – 3 3/4″ x 3 1/4″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56073- RA8 DIXIT LED - Recessed - 9W / 12W LED - 2700K - 3000K / 4000K - CRI 80 - 26° - Matte White
Dixit by Ivela – 4 1/16″ x 3 3/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56077- RA8 Soft Dixit LED - Recessed - 9W / 12W LED - 2700K / 3000K - CRI 90 - Optic 26° - Matte White
Dixit by Ivela – 6 5/16″ x 1 5/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56102- RA16 - Dixit - Recessed - 18W LED - 2700K/3000K/3500K/4000K - CRI 85 - IP44 - Matte White - Optic 110°
Dixit by Ivela – 3 1/8″ x 1 1 15/16″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural A56121- RA8 DIXIT LED - Recessed - 5.5W / 8.5W LED - 2700K / 3000K / 3500K / 4000K - Optic 26° - White - Black Baffle
Dixit by Ivela – 3 1/8″ x 2 15/16″ Recessed, offers high performance and quality material | Zaneen Exterior E5607021- RA8 DIXIT LED - Recessed - 1575lm - 12W LED - 2700K - CRI >80 - IP44 - 26° - White
Dixit by Ivela – 3 3/4″ x 3 1/2″ Recessed, Downlight offers high performance and quality material | Zaneen Exterior E56096- RA8 DIXIT LED IP66 - Recessed - 12W LED - 2700K / 3000K - CRI 80 - 26° - Matte White
Dixit by Ivela – 3 1/8″ x 3 3/16″ Recessed, Downlight offers high performance and quality material | Zaneen Exterior E56103- RA8 DIXIT LED - Recessed - 9W / 12W - LED - 2700K / 3000K / 4000K - IP65 - 26° - White - Black Baffle
Dixit by Ivela – 2 5/8″ x 7/8″ Recessed, Downlight offers high performance and quality material | Zaneen Exterior E5612021 RA 7 - Recessed - LED - 540lm - 4.6W - 3000K - 120° - White - Remote Driver Required (sold separately)

Downloads

Request Files

Dixit by Ivela – 6 5/16″ x 1 5/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural

Dixit by Ivela – 6 5/16″ x 1 5/8″ Recessed, Downlight offers LED lighting solutions | Zaneen Architectural

Ceiling
Direct
Circle wall or ceiling cut-out

155mm / 6 1⁄8"
Min. Recessing Depth

82mm /
3 1⁄4''
Lens

110
Dimmable
Color rendering index

>85 CRI
Color temperature

2700 / 3000 / 3500 / 4000
Lumen (luminous flux)

1745 / 1781
Certified for North American Standards
Protected against ingress of solid bodies greater than 1mm (wire);protected against water splashed from all directions
Protected against 2 joules impact (equivalent to 0.5kg mass


Fixture Finishes

MWH - Matte White
Note: the color samples are digitally reproduced and may not accurately depict the actual colors.
